Glass Fiber Membrane: Ideal for Air Venting & Gas Filtration, Lot to Lot Quality Consistency

Glass fiber filter membrane is a material used for filtration, it is made of 100% glass fiber. According to different applications, glass fiber filtration membranes can be divided into many types, such as air and gas monitoring, pre-filtration, and so on. Among them, glass microfiber filters (with adhesives) are often used to monitor air and gases or as pre-filtration. They are produced with a synthetic adhesive to ensure that the filter membrane has a determined strength. Binderless glass microfiber filters are recommended for analytical and gravimetric analysis and as pre-filtration. Quartz microfiber filters are particularly suitable for emission monitoring at high temperatures and other use cases where membrane purity is highly required.

The glass fiber filter membrane produced by our company XINNA is mainly used for medical air purification.This filter membrane has the advantages of high efficiency filtration, low resistance and long service life, and most importantly, it can withstand high temperatures.

In infusion equipment, the air from the air intake needs to be filtered before entering the equipment to ensure the normal operation of the equipment. Glass fiber filtration membranes can effectively remove particles and bacteria from the air, thereby protecting patients from infection. At the same time, it can also remove odors and harmful gases in the air, improve air quality, and make patients more comfortable during the infusion process.

Features

• Hydrophobic
• High flow rates
• High wet strength
• High operating temperatures
• Superior chemical resistance
• Lot to lot quality consistency

Specification

Applications

Glass fibre membranes are widely used as a general prefilter to remove large particles prior to further filtration, in addition to this, it has many other applications including,

• Gas filter
• Air venting in IV infusion sets
• Disposable Masks and Respirators
• Precipitating proteins and cell filtration
• HEPA air filter

Founded in 1994, Zhejiang XINNA Medical Device Technology Co.,ltd is a trusted and professional manufacturer of high-quality membrane filtration products. As a high-tech enterprise integrating R&D, production and sales,  Xinna provides a wide range of membrane filter products and solutions in the process of filtration, sterilization and purification. ln terms of core technology, it owns 7 patented technologies of joint research and development of filter membranes with one of the best Universities in China. The Nylon, PES, PP, PVDF, PTFE and other membrane filters from us are widely used in medical devices,laboratory, healthcare, air filtration and more fields.

Facilities

Our 161,458 square feet facilities are located in Zhejiang Province of China, with 75,347 square feet as Class 100,000 Cleanroom. This allows us to provide a superior level of cleanliness and contaminate-free status of products to our customers including medical device manufacturers, laboratories and healthcare professionals all around the world.

Featured Products

1. Inline IV Filters & extension lines with IV filters & Transducer protectors

• PTFE membrane for air evacuation
• Single or double-layer PES membrane as filter media
• Pore size: 0.22μm, 0.45μm,1.2μm, 2μm, 3μm, 5μm

Certificates

We hold the ISO 9001:2009 and ISO 13485:2003 Certificates, committed to maintaining a high standard of quality and safety in our operation to ensure our products and services meet our customers’ needs.
